Facility & Equipment

Equipment We Use for Electronics Contract Manufacturing

You are invited to see our Pride in Precision in action by visiting our 42,000-square foot facility, located in the heart of the Mission Valley, midway between Missoula and Kalispell, MT. The facility consists of 3 buildings that accommodate our progressive automated equipment used for manufacturing, inspection and test. There is also a fully equipped machine shop to support providing our customers with quality cable and wire harness assemblies, electromechanical box builds and circuit card assemblies on time.

Circuit Boards

Primary Circuit Card Manufacturing Equipment

CIRCUIT BOARDS

Manufacturer / Model Description

  • Grieve / 333 (qty 4) Curing Ovens
  • Mirtec MV-6 OMNI 3D (qty 2)
  • Cencorp / 1001SR Panel Router / Depanelizer
  • Universal / Advantis X (qty 2) Pick & Place Systems – Lightning Head
  • Universal / Advantis X (qty 2) Pick & Place Systems 7-Spindle Head
  • FKN Systek / K3000S Linear Blade Depanelizer
  • Hepco / Model 8000-1 Axial Lead Cutting & Forming System
  • Hepco / Model 3000-2 Lead Cutting System
  • Electrovert Aquastorm 100C
  • Electrovert Free Standing Wash Module
  • Rehm / VXS 522
  • Rehm / VXS 523
  • Ace Productions / KNG-40 Nitrogen Generation System
  • Dispense Works / RP-1215 Compound (Epoxy) Dispenser
  • ACD / Super M.O.L.E. Gold 6 Channel Temperature Profiler
  • Ace Productions / KISS-103 Selective Wave Solder System
  • Ace Productions / KISS-103 Gen II Selective Wave Solder System
  • Seika Machinery / DXU-1001(qty 2) Temp/Humidity Chambers
  • Seika Machinery / MCU-301 SE Temp/Humidity Chamber
  • Aqueous Technologies / AQ-201SC Ultrasonic Stencil Cleaner
  • Dek Horizon 03ix/Dek NeoHorizon 03ix
  • ERSA / IR/PL 650A BGA Rework Station
  • TYCO / Model BMEP-5T Electric Press
  • AON 3D / M2 V1.0.05 – 3D Printer
  • Ultimake S5 Large-Format 3D Printer
  • SCS / PC V - Precision Coat V

Cabling

Primary Cable Manufacturing Equipment

CABLING

Manufacturer / Model Description

  • Molex / T42 Crimp Presses
  • Ideal / 45-754 Wire Processor
  • Penta Power / N/A Cable Braider
  • Grieve / Model 333 Industrial Oven w/ Chart Recorder
  • Schleuniger / HS4140 Hot Stamp Cable Marker
  • Schleuniger / StripCrimp 75 Cut/Strip/Crimp Press
  • Schleuniger / CoaxStrip 5300 Coaxial Cable Stripper
  • Schleuniger / PowerStrip 9500 Auto Cutter and Stripper
  • Schleuniger / PreFeeder 220/9500 Wire Cutter / Stripper
  • RTMC Spectrum Tech / WD-1RX-25 Laser Wire Stripper
  • Tri-Star M100-L/10 Laser Wire Marker

We do RF! Insertion loss and VSWR testing/measurement to 40 GHz via our HP8720D VNA and our Anritsu S820E-040 SiteMaster.

Inspection & Testing

Primary Inspection & Test Equipment

INSPECTION & TESTING

Manufacturer / Model Description

  • Yxlon Y-Cougar SMT BGA X-Ray Station
  • Mitutoyo/B706 Coordinate Measuring Machine
  • Daniels/Alphatron/MPT-2000A Wire Crimp Pull Tester
  • DITMCO International/2115 Wiring Analyzer (600 point)
  • DITMCO International/2650 Wiring Analyzer (1000 point)
  • DITMCO International/2650 Wiring Analyzer (3000 point)
  • Hewlett-Packard/HP3070 In Circuit Tester (ICT)
  • Ckecksum MDA/TR-8 Manufacturing Defect Analyzer
  • Aqueous Tech ZI-100A Zero Ion Cleanliness Tester
  • Cirris/Signature 1000 H+ Cable/Harness Tester
  • Ckecksum/EMS/FT Manufacturing Defect Analyzer
  • Ransco/7303-1 Thermal Shock Chamber
  • Tenney/ "C-EVO" C20C2.0-A-RMC-B Environmental Test Chamber
  • Sun Electronics/EC13HA Thermal Test Chamber
  • Cirris/Signature 1000HX Cable/Harness Tester
  • Mirtec MV-6 OMNI 3D (qty 2)
  • Hioki / 1240-01 X–Y In Circuit HiTester
  • Huntron/Protrack Probing Station Flying Probe Test Station
  • Cirris Signature 1100R+ cable/harness tester
  • Keyence / IM7020 Optical Comparator

Also, Standard Bench Test Equipment to Support Custom Functional Testing.

Machine Shop

Primary Machine Shop Manufacturing Equipment

MACHINE SHOP

Manufacturer / Model Description

  • Bridgeport 9 X 42 Trackmill w/ Powerfeed
  • Fadal/EMC 3-Axis CNC Milling Centers
  • Birmingham 9 X 48 Vertical Mill
  • Mitutoyo/B706 Coordinate Measuring Machine
  • SGS / Model 18M 6” X 18” Surface Grinder
  • Takisawa / TSL-800D Engine Lathe 14” Swing & 48” Bed
  • J & L / MBS1014W-3 Horizontal Band Saw
  • RPM / TRAK DPMSX2 TRAK DPM2
